COPPUS JECTAIR HP Venturi Air Movers

COPPUS JECTAIR® HP AND HORNET HP High-Performance, Highly Efficient Venturi Air Movers.

The unmatched performance of the COPPUS Jectair® HP is recognized throughout the industry. When compared with older-style air horns, the patented air mixing chamber of the Jectair® HP can produce up to a 40:1 air flow conversion and up to 26 percent savings on compressed air consumption.

Operating Principle: Compressed air or steam is admitted into the Jectair through a single inlet connection in the housing leading to the mixing chamber. The air or steam jetted from the nozzle creates a “Venturi” action that induces a large volume of surrounding air to enter the Jectair through the aerodynamic inlet bell. The air is then discharged at high velocity through the horn-shaped diffuser.

Note: Operating efficiency depends on compressed air volume and pressure (see tables below)

Features & Advantages of the COPPUS JECTAIR

  • Standard Jectair in five sizes: 3SHP, 3HP, 6HP, 8, or 9
  • Heavy-gauge steel diffusers; aluminum diffusers available on 3HP & 6HP model
  • Compressed air or steam operated
  • Air flows range from 1,370 to 8,900 cfm (2,328 to 15,121 m3/hr)
  • Induction ratios up to 40:1
  • Multiple expansion nozzles machined into housing
  • High static pressure capabilities
  • No moving parts; virtually maintenance free
  • Static bonding cable with spring tension grip and replaceable contact tips.
  • Easily attach duct to outlet diffuser end
  • Inlet duct adapter available (optional)
  • Tripod for stationary mounting available (optional)
Category:

Description

Features & Advantages of the COPPUS HORNET HP

  • Hornet HP models available in three sizes: 3SHP, 3HP, & 6HP
  • Features a lightweight, shock-resistant, conductive polymer diffuser that is virtually indestructible
  • Polymer safely dissipates static electricity charges
  • Diffuser is constructed of linear low-density polyethylene
  • UL 94 rating with maximum operating temperature of 160°F (93°C)
  • Compressed air operated only
  • Air flows range from 1,370 to 8,900 cfm (2,328 to 15,121 m3/hr)
  • Induction ratios up to 40:1
  • Multiple expansion nozzles machined into housing
  • High static pressure capabilities
  • No moving parts; virtually maintenance free
  • Static bonding cable with spring tension grip and replaceable contact tips.
  • Easily attach duct to outlet diffuser end
  • Inlet duct adapter available (optional)
  • Tripod for stationary mounting available (optional)

Safety Precautions

  • Use bonding cables when operating in hazardous locations to prevent static electricity discharges
  • Secure unit before admitting compressed air (or steam) to prevent damage or injury from high-reaction force
  • Do not allow solid objects or debris to enter inlet housing during operation
  • When exhausting fumes from an enclosed vessel, take care not to create a vacuum that could collapse the vessel

Accessories

  • Inlet Duct Adapter (3SHP, 3HP, 6HP, 8 & 9)
  • Pipeline Adapter (3HP & 6HP)
  • Tripod Stands (3SHP, 3HP & 6HP)
  • Filter Sock (6HP only)
  • Duct (8” Heavy duty, Conductive or Polyvinyl – 3SHP & 3HP)
  • Duct (12” Heavy duty, Conductive or Polyvinyl – 6HP)
  • Duct (16” Heavy duty, Conductive or Polyvinyl – 8 & 9)
  • Duct Canisters (8”, 12” & 16”)

Dimensions

Coppus-Jectair-HP-Hornet-HP-dimensions

PHYSICAL DIMENSIONS
Jectair A B C D E No. Width Duct Size Net Wt.
in mm in mm in mm in mm in mm in mm in mm lbs kg
3S-HP 6.0 152 16.5 419 7.5 190 0.5 13 6.5 165 3 0.4 10 8 203 6 2.7
3-HP 7.3 185 33.0 838 7.5 190 0.5 13 6.5 165 3 0.4 10 9 4.1
6-HP 12.0 305 44.2 1,123 11.5 292 1 25 10.8 274 3 0.4 10 12 305 21 9.5
8 14.0 356 46.0 1,168 14.3 363 1 25 13.5 345 3 0.5 13 14 356 35 15.9
9 14.0 356 46.0 1,168 16.8 427 1 25 15.3 387 10 0.9 23 42 19

Performance

PERFORMANCE THROUGH VARIOUS LENGTHS OF DUCT (80 PSIG or 7 KG/CM2)
Jectair Free Air 20 ft (6 m) 30 ft (9 m) 40 ft (12 m) 50 ft (15 m)
cfm m3/hr cfm m3/hr cfm m3/hr cfm m3/hr cfm m3/hr
3-HP 1,700 2,888 1,550 2,634 1,480 2,515 1,4102,396 2,3961,350 1,3502,294 2,294
6-HP 4,500 7,645 4,020 6,830 3,860 6,558 3,715 6,312 3,580 6,083
8 6,250 10,620 5,550 9,431 5,280 8,972 5,050 8,581 4,850 8,241
9 8,000 13,592 6,850 11,640 6,550 11,130 6,250 10,620 6,000 10,195

Efficiency

EFFICIENCY AT INLET PRESSURES
Inlet Pressure Jectair Air Flow Air Consumption Induction Ratio Block Tight
Static Pressure
cfm m3/hr cfm m3/hr in mm
60 psig
or
4.2 kg/cm2		 3S-HP 1,370 2,328 47 80 29.1 5.8 147
3-HP 1,520 2,595 47 80 32.3 5.8 147
6-HP 3.980 6.762 98 167 40.6 4.3 109
8 5,600 9,515 178 302 31.5 3.9 99
9 6.880 11,096 265 450 25.8 5.5 140
80 psig
or
5.6 kg/cm2		 3S-HP 1,530 2,600 61 104 25.1 7.5 191
3-HP 1,700 2,888 61 104 27.8 7.5 191
6-HP 4,500 7,645 126 214 35.7 5.6 132
8 6,250 10,620 233 396 26.8 5.2 132
9 8,000 13,592 366 571 23.8 6.8 173
100 psig
or
7.0 kg/cm2		 3S-HP 1,660 2,820 72 122 23.0 8.9 224
3-HP 1,860 3,160 72 122 25.8 8.9 224
6-HP 4,870 8,274 153 260 31.8 6.7 170
8 6,750 11,469 282 479 23.9 6.2 157
9 8,900 15,121 410 697 21.7 7.7 196
* Maximum Operating Pressure 150 psig (10.5 kg/cm2)
* Induction Ratio = Air Flow/Air Consumption
